DE-PALLETIZER
Knight Industrial has palletizers and depalletizers that are designed to load or unload stacks of dairy cases onto or off of pallets. Designed to fit your specific needs, and to handle large loads, our Palletizers and De-Palletizers will accomplish labor intensive tasks in a fraction of the time. These machines are available in on-floor ratchet or above floor chain styles and can be configured into a u-style to allow placement into a corner of a building.
Specifications
3 x 3 square tube frame
Stainless steel construction
3" stainless steel pallet skid runners (3) that are 3" wide
2 hydraulic side ratchets
10 amps @ 1/60/115 vac (volts AC)
25 gallons per minute (GPM) hydraulics at 600 pounds per square inch (psi)
Key Features
Over-head type empty stack pusher
Hanging backstop that monitors (by PLC) if stacks tip
Side-Ratchet type pallet transfer
Pallet jack type access magazine
1400 Micrologix PLC with Allen-Bradley PLC
Hydraulically operated electronically controlled
In-line, U-flow or 90° empty magazine infeed configuration
Pallet Sizes: 40 x 40 - 9 pattern, 40 x 52 - 12 pattern.
Over-head type empty stack pusher
Hanging backstop that monitors (by PLC) if stacks tip
Side-Ratchet type pallet transfer
Pallet jack type access magazine
1400 Micrologix PLC with Allen-Bradley PLC
Hydraulically operated electronically controlled
In-line, U-flow or 90° empty magazine infeed configuration
Pallet Sizes: 40 x 40 - 9 pattern, 40 x 52 - 12 pattern.
Integrations
Forklift-style availableAbove floor chain-type pallet conveyorPallet stations available in 4, 5, or 6 configurationsRemote hydraulic power packDiagnostic display includedStock conveyor drive is sold separately.
Helping You Do What You Do, Better
Our engineering team can customize this equipment to your exact specifications. Contact us to discuss your requirements.
