Key Features

3498 / 3500 Chain Compatible

Purpose-built for Knight Industrial 3498 and 3500 series dairy conveyor chains. Front opening accepts chain links directly with self-aligning geometry.

Hydraulic Cylinder Drive

Integrated 11137-109 hydraulic assembly with 4002 pump and 4103 single ram delivers consistent, controlled force for smooth chain pin extraction.

Dual-Slide Mechanism

Pusher blocks and chain guides work in tandem inside the machined housing for precise, controlled pin removal. Color-coded internals simplify field maintenance.

Robust Construction

Machined steel body assembled with 17x SHCS .500-13 fasteners around the perimeter. Shoulder bolts and set screws provide precision alignment of all internal components.

13 Custom Machined Parts

Parts 11137-101 through 11137-115 — every component individually replaceable for maximum service life. Full CAD data available in Inventor .iam format.

Portable Field Tool

Integrated MH268-401405 carry handles, compact block footprint, and self-contained hydraulics. A true portable tool for on-line chain maintenance.

Technical Specifications

Part Number	11137-1000
Application	3498 / 3500 Series Chain Pin Extraction
Drive	Hydraulic — 4002 Pump / 4103 Single Ram
Custom Parts	13 machined (11137-101 through 11137-115)
Primary Fasteners	17x SHCS .500-13 x 1.250 (perimeter)
Body Construction	Machined Tool Steel
Mechanism	Dual slide block + chain guides
Portable	Yes — MH268-401405 carry handles (x2)
Field Serviceability	Fully rebuildable, all parts replaceable
OEM	Knight Industrial Inc. — Exclusive Design

Contact Knight Industrial today at (844) 564-4489 or info@knightindustrialinc.com to order the Chain Breaker or any replacement components.
